General Features
OUTPUT POWER 55 W
PRE OUT 3 Pre Out
SUB OUT Yes
ZONE X ZONE No
AUX-IN No
REAR VIEW CAMERA IN Yes
USB Yes (Rear x1)
NAVIGATION No
FIRMWARE UPGRADABILITY Yes
VIDEO OUT No
TIME ALIGNMENT No
EQUALIZER 10-Band Graphic Equalizer
ALBUM ARTWORK INDICATION Yes
Connectivity
BLUETOOTH Yes
NFC No
Tuner Features
PRESET FM18 / AM12
AUTO MEMORY BTM
RDS / EON Yes (Only RDS)
Bluetooth Profile
HFP 1.5 Yes (1.6)
A2DP Yes (1.2)
OPP No
SPP No
AVRCP Yes (1.4)
PBAP Yes (1.1)
Bluetooth Feature
SPEED DIAL Yes (6 memories)
RECENT CALLS (# OF) Yes (20 numbers)
LAST DIALED CALL YES (select from the dialed call history)
PHONEBOOK ACCESS VIA PBAP Yes
ALPHABETICAL PHONEBOOK SORTING Yes
AUTO ANSWER Yes (off/on)
RING VOLUME LEVEL CONTROL Yes
CALL VOLUME LEVEL CONTROL Yes
EXTERNAL MICROPHONE Supplied
BATTERY REMAINDER INDICATION Yes
SIGNAL STRENGTH INDICATION Yes
Bluetooth Audio Feature
AUDIO CODEC (BLUETOOTH AUDIO) SBC
PAUSE (BLUETOOTH AUDIO) Yes
CUE / VER Yes
TRACK +/- Yes
GROUP (FOLDER) +/- Yes
AUDIO LEVEL ADJUSTMENT Yes (-8 dB to +18 dB)
REPEAT CONTROL (AUDIO DEVICE SIDE) Yes
SHUFFLE CONTROL (AUDIO DEVICE SIDE) Yes
META DATA INDICATION Yes
Panel Design
PANEL SURFACE FINISH COLOR Black
KEY ILLUMINATION Yes (White)
PANEL DETACHABILITY No
Monitor(AVC)
LCD TYPE TFT Active Matrix
SCREEN ASPECT 5:09 PM
SCREEN DIAGONAL (INCH / MM) 6.4 inch
SCREEN SIZE (W X H MM) 5.65 * 3.02 (in)
RESOLUTION (DOT) 800 × 480
DIMMER Yes
CONTRAST RATIO 600
BRIGHTNESS 3.72 cd/ft2
Display Panel
KEY ILLUMINATION INITIAL Yes (White)
DIMMER ADJUST Yes
User Interface
TOUCH PANEL Yes
GESTURE COMMAND Yes
REMOTE COMMANDER ( ): OPTIONAL RM-X170
PARKING CONTROL Yes
ASPECT RATIO SELECT Yes
REAR VIEW CAMERA-IN MARKER SETTING Yes
